Cams
Showing 1–16 of 34 results
P2091
Part Description
Cam, CT, LH Top/RH Bottom
• P20911 – Plain
• P20915 – HDG
Use With
• P1064 – Keeper, DL/CT, Weld-on, 0″ offset
• P2093 – Keeper, DL/CT, Bolt-on, 0″ offset (No longer available. Replaced by P4468)
• P4468 – Keeper, DL/CT, Bolt-on, 0″ Offset (Replaces P2093)
Features & Benefits
Dual-Lobe Zero-Torque Model Application. Dual ferrule provides added anti-rack and end load protection for marine/cargo container applications.
Dual-Lobe, Zero-Torque models provide an ideal combination of benefits for the problems associated with trailer and container door securement.
Zero-Torque cams provides 100% positive anti-rack control in all directions.
Provides secure closure since the more load against the door from the inside, the tighter the lockrod engages.
Dual-Lobe design provides “ice breaker” action, providing opening leverage that frees frozen or stuck doors, and overcomes stiff or frozen seals, regardless of door thickness.
P2092
Part Description
Cam, CT, RH Top/LH Bottom
• P20921 – Plain
• P20925 – HDG
Use With
• P1064 – Keeper, DL/CT, Weld-on, 0″ offset
• P2093 – Keeper, DL/CT, Bolt-on, 0″ offset (No longer available. Replaced by P4468)
• P4468 – Keeper, DL/CT, Bolt-on, 0″ Offset (Replaces P2093)
Features & Benefits
Dual-Lobe Zero-Torque Model Application. Dual ferrule provides added anti-rack and end load protection for marine/cargo container applications.
Dual-Lobe, Zero-Torque models provide an ideal combination of benefits for the problems associated with trailer and container door securement.
Zero-Torque cams provides 100% positive anti-rack control in all directions.
Provides secure closure since the more load against the door from the inside, the tighter the lockrod engages.
Dual-Lobe design provides “ice breaker” action, providing opening leverage that frees frozen or stuck doors, and overcomes stiff or frozen seals, regardless of door thickness.
P2497
Part Description
Cam, HV, 3/4-inch or 1-inch RH Top/LH Bottom
• P24971 – Plain
• P24975 – HDG
• P24977 – SS
Use With
• P2496 – Keeper, HV, Bolt-on, 0″ offset
• P4223 – Keeper, HV, Weld-on, 0″ offset
Features & Benefits
Reach and Gather Model Designed for high-cube trailers and domestic containers.
Cams can reach keepers 2-1/4 inches away from lockrod centerline.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Provides opening leverage to free frozen or stuck doors, or overcome stiff or frozen seals.
P2498
Part Description
Cam, HV, 3/4-inch or 1-inch LH Top/RH Bottom
• P24981 – Plain
• P24985 – HDG
• P24987 – SS
Use With
• P2496 – Keeper, HV, Bolt-on, 0″ offset
• P4223 – Keeper, HV, Weld-on, 0″ offset
Features & Benefits
Reach and Gather Model Designed for high-cube trailers and domestic containers.
Cams can reach keepers 2-1/4 inches away from lockrod centerline.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Provides opening leverage to free frozen or stuck doors, or overcome stiff or frozen seals.
P4043
Part Description
Cam, DL, LH Top/RH Bottom
• P40431 – Plain
• P40435 – HDG
Use With
• P1064 – Keeper, DL/CT, Weld-on, 0″ offset
• P2093 – Keeper, DL/CT, Bolt-on, 0″ offset (No longer available. Replaced by P4468)
• P4468 – Keeper, DL/CT, Bolt-on, 0″ Offset (Replaces P2093)
Features & Benefits
Dual-Lobe, Zero-Torque Model Application. Dual-ferrule provides added anti-rack and end-load protection for marine/cargo container applications.
Dual-Lobe, Zero-Torque models provide an ideal combination of benefits for the problems associated with trailer and container door securement.
Zero-Torque cams provides 100% positive anti-rack control in all directions.
Provides secure closure since the more load against the door from the inside, the tighter the lockrod engages.
Dual-Lobe design provides “ice breaker” action, providing opening leverage that frees frozen or stuck doors, and overcomes stiff or frozen seals, regardless of door thickness.
P4044
Part Description
Cam, DL, RH Top/LH Bottom
• P40441 – Plain
• P40445 – HDG
Use With
• P1064 – Keeper, DL/CT, Weld-on, 0″ offset
• P2093 – Keeper, DL/CT, Bolt-on, 0″ offset (No longer available. Replaced by P4468)
• P4468 – Keeper, DL/CT, Bolt-on, 0″ Offset (Replaces P2093)
Features & Benefits
Dual-Lobe, Zero-Torque Model Application. Dual-ferrule provides added anti-rack and end-load protection for marine/cargo container applications.
Dual-Lobe, Zero-Torque models provide an ideal combination of benefits for the problems associated with trailer and container door securement.
Zero-Torque cams provides 100% positive anti-rack control in all directions.
Provides secure closure since the more load against the door from the inside, the tighter the lockrod engages.
Dual-Lobe design provides “ice breaker” action, providing opening leverage that frees frozen or stuck doors, and overcomes stiff or frozen seals, regardless of door thickness.
P4073
Part Description
Cam, FC, 3/4-inch, Universal LH/RH
• P40731 – Plain
• P40735 – HDG
• P40737 – SS
Use With
• P4009 – Keeper, WS/FC, Weld-on, 0″ offset
• P4064 – Keeper, WS/FC, Bolt-on, 0″ offset
• P4380 – Keeper, WS/FC, Bolt-on, 0″ offset
Features & Benefits
The 3/4-inch finger cam ideal for light and medium-duty side and rear door applications.
Saddle Cam model slips over tubing, providing simple lockrod assembly, and is an economical choice for the custom manufacture of lockrods from kits.
P4141
Part Description
Cam, NH, LH Top/RH Bottom
• P41411 – Plain
• P41415 – HDG
• P41417 – SS
Use With
• P4140 – Keeper, NH, Weld-on, 0″ offset
• P4374 – Keeper, NH, Bolt-on, 0″ offset
Features & Benefits
Dual-Lobe, Zero-Torque models provide an ideal combination of benefits for the problems associated with trailer and container door securement.
Zero-Torque cams provides 100% positive anti-rack control in all directions.
Provides secure closure since the more load against the door from the inside, the tighter the lockrod engages.
Dual-Lobe design provides “ice breaker” action, providing opening leverage that frees frozen or stuck doors, and overcomes stiff or frozen seals, regardless of door thickness.
P4142
Part Description
Cam, NH, RH Top/LH Bottom
• P41421 – Plain
• P41425 – HDG
• P41427 – SS
Use With
• P4140 – Keeper, NH, Weld-on, 0″ offset
• P4374 – Keeper, NH, Bolt-on, 0″ offset
Features & Benefits
Dual-Lobe, Zero-Torque models provide an ideal combination of benefits for the problems associated with trailer and container door securement.
Zero-Torque cams provides 100% positive anti-rack control in all directions.
Provides secure closure since the more load against the door from the inside, the tighter the lockrod engages.
Dual-Lobe design provides “ice breaker” action, providing opening leverage that frees frozen or stuck doors, and overcomes stiff or frozen seals, regardless of door thickness.
P4144
Part Description
Cam, SC, Secura, RH
• P41441 – Plain
• P41445 – HDG
Use With
• P4143 – Keeper, SC, Secura, Weld-on, RH, 0″ offset
Features & Benefits
This security option provides a way to secure the door seal directly at the cam and keeper, instead of at the lockrod handle. Holes are provided through the cam and the keeper, which line up when the lockrod in the closed psoition. This security seal is then attached through the cam and keeper, making the door impossible to open without the seal being broken.
Compatibility with Powerbrace DL or CT lockrod models
Accepts barrier and integrity seals
Requires only one RH Secura-Cam/Keeper Assembly per end-frame
P4147
Part Description
Cam, WS, 3/4-inch or 1-inch LH Top/RH Bottom
• P41471 – Plain
• P41475 – HDG
Use With
• P4009 – Keeper, WS/FC, Weld-on, 0″ offset
• P4064 – Keeper, WS/FC, Bolt-on, 0″ offset
• P4380 – Keeper, WS/FC, Bolt-on, 0″ offset
Features & Benefits
Suited for both rear and side door applications, and is an excellent choice where severe duty service is not required.
Can be used for both 3/4-inch side and rear door applications, as well as 1 inch rear door applications.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Cams can reach keepers 2 inches from lockrod centerline.
Provides opening leverage to free stuck or frozen doors, or overcome stiff or frozen seals.
P4148
Part Description
Cam, WS, 3/4-inch or 1-inch RH Top/LH Bottom
• P41481 – Plain
• P41485 – HDG
Use With
• P4009 – Keeper, WS/FC, Weld-on, 0″ offset
• P4064 – Keeper, WS/FC, Bolt-on, 0″ offset
• P4380 – Keeper, WS/FC, Bolt-on, 0″ offset
Features & Benefits
Suited for both rear and side door applications, and is an excellent choice where severe duty service is not required.
Can be used for both 3/4-inch side and rear door applications, as well as 1 inch rear door applications.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Cams can reach keepers 2 inches from lockrod centerline.
Provides opening leverage to free stuck or frozen doors, or overcome stiff or frozen seals.
P4153
Part Description
Cam, SH, LH Top/RH Bottom
• P41531 – Plain
• P41535 – HDG
• P41537 – SS
Use With
• P4155 – Keeper, SH, Weld-on, LH Top/RH Bottom, 0″ offset
Features & Benefits
Reach and Gather Model Designed for high-cube trailers.
Cams can reach keepers 2-1/4 inches away from lockrod centerline.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Provides opening leverage to free stuck or frozen doors, or overcome stiff or frozen seals.
P4154
Part Description
Cam, SH, RH Top/LH Bottom
• P41541 – Plain
• P41545 – HDG
• P41547 – SS
Use With
• P4156 – Keeper, SH, Weld-on, RH Top/LH Bottom, 0″ offset
Features & Benefits
Reach and Gather Model Designed for high-cube trailers.
Cams can reach keepers 2-1/4 inches away from lockrod centerline.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Provides opening leverage to free stuck or frozen doors, or overcome stiff or frozen seals.
P4201
Part Description
Cam, QF, LH Top/RH Bottom
• P42011 – Plain
• P42015 – HDG
Use With
• P4237 – Keeper, QF, Weld-on, 0″ offset
Features & Benefits
Reach and Gather Model Quad Finger system for marine containers.
Cams can reach keepers 2-1/4 inches away from lockrod centerline.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Provides opening leverage to free stuck or frozen doors, or overcome stiff or frozen seals.
P4202
Part Description
Cam, QF, RH Top/LH Bottom
• P42021 – Plain
• P42025 – HDG
Use With
• P4237 – Keeper, QF, Weld-on, 0″ offset
Features & Benefits
Reach and Gather Model Quad Finger system for marine containers. Cams can reach keepers 2-1/4 inches away from lockrod centerline.
Offers maximum reach and gather to square racked end-frames and/or warped doors.
Provides opening leverage to free stuck or frozen doors, or overcome stiff or frozen seals.
